Lightweight Wheel Track Surveillance Robot With Voice Monitoring Supported

  • Lightweight Wheel Track Surveillance Robot With Voice Monitoring Supported
  • Lightweight Wheel Track Surveillance Robot With Voice Monitoring Supported
  • Lightweight Wheel Track Surveillance Robot With Voice Monitoring Supported
  • Lightweight Wheel Track Surveillance Robot With Voice Monitoring Supported
Place of Origin China
Brand Name Particle
Model Number R30S
Minimum Order Quantity 1
Price $27,160
Payment Terms T/T

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Dual-mode Observation Visible Light And Thermal Imaging Applications Can Be Used For Reconnaissance In Various Terrains And Environments
Product Category Miniature Reconnaissance Robot Thermal Imaging Display Modes White Heat, Black Heat, False Color, And Outline
Ultra Waterproof Performance Excellent Wading Ability Mobility Remote-controlled
Wheel-Crawler Composite Design Shows Excellent Through Performance Auxiliary-Support-Arm Ensures The Robot Can Quickly Right Itself If It Overturns
Robot Weight ≤3kg（Including Battery） Daytime Detection Distance 50m, Recognition Distance 20m;
Night Detection Distance 25m, Recognition Distance 10m Horizontal FOV ≥60°
Overcoming Obstacles ≥10cm Climbing ≥35°
Drop Height ≥4m Working Time ≥2h
CCD Resolution 1/3in，720×576 IR Resolution 384×288@17μm
Driving Capability Foliage, Sandy Slopes, Wading Controller Working Time ≥3.5h
Controller Weight ≤1.2kg（Including Battery） Memory Card 32G（Build In）
Control Method Joystick + Button Remote Control Outdoor ≥350m
Remote Control Indoor ≥50m IP Grade ≥IP67
Operation Temperature －40℃～+55℃
Highlight

Lightweight surveillance robot

,

Track surveillance robot

,

Voice Monitoring military surveillance robot
Leave a Message
Product Description



Lightweight Wheel-track Surveillance Robot with Voice Monitoring Supported



APPLICATIONS

Introducing the JP R30S, a versatile small wheel-track composite reconnaissance robot designed for rapid deployment and reconnaissance. It can be thrown into a scene or break through windows to enter buildings, performing crucial reconnaissance missions. Remote control allows it to approach targets stealthily or take immediate action. Its crawler design ensures it navigates through complex terrains like underground pipes, caves, jungles, and grasslands with ease. The innovative "dual vision" system, featuring a front thermal imaging sensor and a rear visible light image sensor, enables it to capture thermal imaging videos and visible light images even in low-light conditions, ensuring 24/7 operational capability. The Auxiliary-Support-Arm helps it quickly recover from overturning.



FUNCTION

►The dual-mode observation with visible light and thermal imaging
►Support IR auxiliary illumination
►Four thermal imaging display modes: white heat,black heat, false color, and outline
►Display of PIP(picture-in-picture)
►Voice monitoring
►Support photo and video recording, local browsing and export
►Can adjust the display brightness
►Support 3-speed change



Features

► Adopt wheel-crawler composite design, showing excellent through performance
► "Double-view"design,free switching between visible light observation mode and thermal imaging observation mode
► Unique arm design,quickly adjust the posture of the body
► Strong impact-resistant design,can be thrown to the target area

► Ultra waterproof performance, excellent wading ability


Technical Parameters:



1. Robot
(1)Weight ≤3kg(Including battery);
(2)Daytime Detection distance 50m, recognition distance 20m;
(3)Night Detection distance 25m, recognition distance 10m;
(4)Horizontal FOV ≥60°;
(5)Overcoming Obstacles ≥10cm;
(6)Climbing ≥35°;
(7)Drop Height ≥4m;
(8)Working Time ≥2h;
(9)CCD Resolution 1/3in,720×576;
(10)IR Resolution 384×288@17μm;
(11)Capable of driving in foliage, sandy slopes and wading;
2.Controller
(1)Working Time ≥3.5h;
(2)Weight ≤1.2kg(Including battery);
(3)Memory Card 32G(Build in);
(4)Control Method: Joystick + button;
3. Remote Control
(1)Outdoor ≥350m;
(2)Indoor ≥50m;
4.IP grade ≥IP67;
5.Operation Temperature －40℃～+55℃.



R30S Details

Lightweight Wheel Track Surveillance Robot With Voice Monitoring Supported 0
