Tracked Scout Robot Multi Functional Reconnaissance System For Tactical Use

  • Tracked Scout Robot Multi Functional Reconnaissance System For Tactical Use
  • Tracked Scout Robot Multi Functional Reconnaissance System For Tactical Use
  • Tracked Scout Robot Multi Functional Reconnaissance System For Tactical Use
  • Tracked Scout Robot Multi Functional Reconnaissance System For Tactical Use
Place of Origin China
Brand Name Particle
Model Number R30S
Minimum Order Quantity 1
Price $27,160
Payment Terms T/T

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Weight Lightweight Size Small
Terrain Adaptability All-terrain Durability Robust
Stealth Capability Silent Mobility Remote-controlled
Robot Weight ≤3kg（Including Battery） Daytime Detection Distance 50m, Recognition Distance 20m;
Night Detection Distance 25m, Recognition Distance 10m Horizontal FOV ≥60°
Overcoming Obstacles ≥10cm Climbing ≥35°
Drop Height ≥4m Working Time ≥2h
CCD Resolution 1/3in，720×576 IR Resolution 384×288@17μm
Driving Capability Foliage, Sandy Slopes, Wading Controller Working Time ≥3.5h
Controller Weight ≤1.2kg（Including Battery） Memory Card 32G（Build In）
Control Method Joystick + Button Remote Control Outdoor ≥350m
Remote Control Indoor ≥50m IP Grade ≥IP67
Operation Temperature －40℃～+55℃
Highlight

Tactical scout robot

,

Multi Functional scout robot

,

Lightweight scout robots
Leave a Message
Product Description



Advanced Tracked Scout Robot Multi-Functional Reconnaissance System for Tactical Use



APPLICATIONS

The JP R30S is a compact wheel-track hybrid reconnaissance robot. It can be deployed into the scene by being thrown or break through windows to enter buildings for missions. Remote control allows it to silently approach targets or launch an active attack. Its crawler design adapts to various terrains, ensuring free movement in underground pipes, caves, jungles, and grasslands. The unique "dual vision" design features a thermal imaging sensor in the front and a visible light image sensor in the rear, enabling it to capture thermal and low-light visible images, making it effective for day, night, and complete darkness reconnaissance. Additionally, the Auxiliary-Support-Arm helps it quickly right itself if overturned.



FUNCTION

►The dual-mode observation with visible light and thermal imaging
►Support IR auxiliary illumination
►Four thermal imaging display modes: white heat,black heat, false color, and outline
►Display of PIP(picture-in-picture)
►Voice monitoring
►Support photo and video recording, local browsing and export
►Can adjust the display brightness
►Support 3-speed change



Features

► Adopt wheel-crawler composite design, showing excellent through performance
► "Double-view"design,free switching between visible light observation mode and thermal imaging observation mode
► Unique arm design,quickly adjust the posture of the body
► Strong impact-resistant design,can be thrown to the target area

► Ultra waterproof performance, excellent wading ability


Technical Parameters:



1. Robot
(1)Weight ≤3kg(Including battery);
(2)Daytime Detection distance 50m, recognition distance 20m;
(3)Night Detection distance 25m, recognition distance 10m;
(4)Horizontal FOV ≥60°;
(5)Overcoming Obstacles ≥10cm;
(6)Climbing ≥35°;
(7)Drop Height ≥4m;
(8)Working Time ≥2h;
(9)CCD Resolution 1/3in,720×576;
(10)IR Resolution 384×288@17μm;
(11)Capable of driving in foliage, sandy slopes and wading;
2.Controller
(1)Working Time ≥3.5h;
(2)Weight ≤1.2kg(Including battery);
(3)Memory Card 32G(Build in);
(4)Control Method: Joystick + button;
3. Remote Control
(1)Outdoor ≥350m;
(2)Indoor ≥50m;
4.IP grade ≥IP67;
5.Operation Temperature －40℃～+55℃.



R30S Details

Tracked Scout Robot Multi Functional Reconnaissance System For Tactical Use 0
