Supported IR Auxiliary Illumination Miniature Reconnaissance Robot

  • Supported IR Auxiliary Illumination Miniature Reconnaissance Robot
  • Supported IR Auxiliary Illumination Miniature Reconnaissance Robot
  • Supported IR Auxiliary Illumination Miniature Reconnaissance Robot
  • Supported IR Auxiliary Illumination Miniature Reconnaissance Robot
Place of Origin China
Brand Name Particle
Model Number R30S
Minimum Order Quantity 1
Price $27,160
Payment Terms T/T

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Size Small Stealth Capability Silent
IR Auxiliary Illumination Supported Product Category Miniature Reconnaissance Robot
Dual-mode Observation Visible Light And Thermal Imaging Terrain Adaptability All-terrain
Display Brightness Adjustment Supported Product Name Miniature Reconnaissance Robot For Multi-terrain Missions
Robot Weight ≤3kg（Including Battery） Daytime Detection Distance 50m, Recognition Distance 20m;
Night Detection Distance 25m, Recognition Distance 10m Horizontal FOV ≥60°
Overcoming Obstacles ≥10cm Climbing ≥35°
Drop Height ≥4m Working Time ≥2h
CCD Resolution 1/3in，720×576 IR Resolution 384×288@17μm
Driving Capability Foliage, Sandy Slopes, Wading Controller Working Time ≥3.5h
Controller Weight ≤1.2kg（Including Battery） Memory Card 32G（Build In）
Control Method Joystick + Button Remote Control Outdoor ≥350m
Remote Control Indoor ≥50m IP Grade ≥IP67
Operation Temperature －40℃～+55℃
Highlight

Small Reconnaissance Robot

,

IR Auxiliary Illumination Reconnaissance Robot

,

Miniature military surveillance robot
Leave a Message
Product Description



Supported IR Auxiliary Illumination Miniature Reconnaissance Robot



APPLICATIONS

The JP R30S is an advanced small wheel-track composite reconnaissance robot designed for challenging missions. It can be thrown into a scene or break windows to enter buildings for reconnaissance. Capable of remote-controlled stealth approaches or proactive attacks, its crawler design adapts to complex terrains like underground pipes, caves, jungles, and grasslands. The unique "dual vision" system includes a front thermal imaging sensor and a rear visible light sensor, allowing it to capture both thermal and visible light images in any lighting condition. An Auxiliary-Support-Arm helps it quickly recover if overturned.



FUNCTION

►The dual-mode observation with visible light and thermal imaging
►Support IR auxiliary illumination
►Four thermal imaging display modes: white heat,black heat, false color, and outline
►Display of PIP(picture-in-picture)
►Voice monitoring
►Support photo and video recording, local browsing and export
►Can adjust the display brightness
►Support 3-speed change



Features

► Adopt wheel-crawler composite design, showing excellent through performance
► "Double-view"design,free switching between visible light observation mode and thermal imaging observation mode
► Unique arm design,quickly adjust the posture of the body
► Strong impact-resistant design,can be thrown to the target area

► Ultra waterproof performance, excellent wading ability


Technical Parameters:



1. Robot
(1)Weight ≤3kg(Including battery);
(2)Daytime Detection distance 50m, recognition distance 20m;
(3)Night Detection distance 25m, recognition distance 10m;
(4)Horizontal FOV ≥60°;
(5)Overcoming Obstacles ≥10cm;
(6)Climbing ≥35°;
(7)Drop Height ≥4m;
(8)Working Time ≥2h;
(9)CCD Resolution 1/3in,720×576;
(10)IR Resolution 384×288@17μm;
(11)Capable of driving in foliage, sandy slopes and wading;
2.Controller
(1)Working Time ≥3.5h;
(2)Weight ≤1.2kg(Including battery);
(3)Memory Card 32G(Build in);
(4)Control Method: Joystick + button;
3. Remote Control
(1)Outdoor ≥350m;
(2)Indoor ≥50m;
4.IP grade ≥IP67;
5.Operation Temperature －40℃～+55℃.



R30S Details

Supported IR Auxiliary Illumination Miniature Reconnaissance Robot 0
