Lightweight Miniature Reconnaissance Robot PIP Display Voice Monitoring

  • Lightweight Miniature Reconnaissance Robot PIP Display Voice Monitoring
  • Lightweight Miniature Reconnaissance Robot PIP Display Voice Monitoring
  • Lightweight Miniature Reconnaissance Robot PIP Display Voice Monitoring
  • Lightweight Miniature Reconnaissance Robot PIP Display Voice Monitoring
Place of Origin China
Brand Name Particle
Model Number R30S
Minimum Order Quantity 1
Price $27,160
Payment Terms T/T

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Voice Monitoring Supported Dual-mode Observation Visible Light And Thermal Imaging
IP Grade ≥IP67 Thermal Imaging Display Modes White Heat, Black Heat, False Color, And Outline
Mobility Remote-controlled Operation Temperature －40℃～+55℃
Product Name Miniature Reconnaissance Robot For Multi-terrain Missions Weight Lightweight
Robot Weight ≤3kg（Including Battery） Daytime Detection Distance 50m, Recognition Distance 20m;
Night Detection Distance 25m, Recognition Distance 10m Horizontal FOV ≥60°
Overcoming Obstacles ≥10cm Climbing ≥35°
Drop Height ≥4m Working Time ≥2h
CCD Resolution 1/3in，720×576 IR Resolution 384×288@17μm
Driving Capability Foliage, Sandy Slopes, Wading Controller Working Time ≥3.5h
Controller Weight ≤1.2kg（Including Battery） Memory Card 32G（Build In）
Control Method Joystick + Button Remote Control Outdoor ≥350m
Remote Control Indoor ≥50m
Highlight

Lightweight Reconnaissance Robot

,

PIP Display Reconnaissance Robot

,

Voice Monitoring outdoor security robot
Leave a Message
Product Description



Lightweight Miniature Reconnaissance Robot PIP Display/ Voice Monitoring



APPLICATIONS

The JP R30S reconnaissance robot is a compact and adaptable solution for tactical operations. Its small wheel-track design allows it to be thrown or break windows to gain entry for reconnaissance missions. It operates via remote control, capable of silent observation or active engagement. The robot's tracks handle diverse terrains like pipes, caves, jungles, and grasslands. Its "dual vision" system includes thermal imaging and visible light sensors, ensuring effective surveillance in all lighting conditions. An Auxiliary-Support-Arm aids in quick recovery if it overturns during missions.



FUNCTION

►The dual-mode observation with visible light and thermal imaging
►Support IR auxiliary illumination
►Four thermal imaging display modes: white heat,black heat, false color, and outline
►Display of PIP(picture-in-picture)
►Voice monitoring
►Support photo and video recording, local browsing and export
►Can adjust the display brightness
►Support 3-speed change



Features

► Adopt wheel-crawler composite design, showing excellent through performance
► "Double-view"design,free switching between visible light observation mode and thermal imaging observation mode
► Unique arm design,quickly adjust the posture of the body
► Strong impact-resistant design,can be thrown to the target area

► Ultra waterproof performance, excellent wading ability


Technical Parameters:



1. Robot
(1)Weight ≤3kg(Including battery);
(2)Daytime Detection distance 50m, recognition distance 20m;
(3)Night Detection distance 25m, recognition distance 10m;
(4)Horizontal FOV ≥60°;
(5)Overcoming Obstacles ≥10cm;
(6)Climbing ≥35°;
(7)Drop Height ≥4m;
(8)Working Time ≥2h;
(9)CCD Resolution 1/3in,720×576;
(10)IR Resolution 384×288@17μm;
(11)Capable of driving in foliage, sandy slopes and wading;
2.Controller
(1)Working Time ≥3.5h;
(2)Weight ≤1.2kg(Including battery);
(3)Memory Card 32G(Build in);
(4)Control Method: Joystick + button;
3. Remote Control
(1)Outdoor ≥350m;
(2)Indoor ≥50m;
4.IP grade ≥IP67;
5.Operation Temperature －40℃～+55℃.



R30S Details

Lightweight Miniature Reconnaissance Robot PIP Display Voice Monitoring 0
