Display Brightness Adjustment Supported Wheeled Tracked Robot With Thermal Imaging

  • Display Brightness Adjustment Supported Wheeled Tracked Robot With Thermal Imaging
  • Display Brightness Adjustment Supported Wheeled Tracked Robot With Thermal Imaging
  • Display Brightness Adjustment Supported Wheeled Tracked Robot With Thermal Imaging
  • Display Brightness Adjustment Supported Wheeled Tracked Robot With Thermal Imaging
Place of Origin China
Brand Name Particle
Model Number R30S
Minimum Order Quantity 1
Price $27,160
Payment Terms T/T

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
IP Grade ≥IP67 Voice Monitoring Supported
Photo And Video Recording Supported Thermal Imaging Display Modes White Heat, Black Heat, False Color, And Outline
IR Auxiliary Illumination Supported Product Name Compact Design Powerful Performance Ocelot Miniature Reconnaissance Robot
Terrain Adaptability All-terrain Weight Lightweight
Robot Weight ≤3kg（Including Battery） Daytime Detection Distance 50m, Recognition Distance 20m;
Night Detection Distance 25m, Recognition Distance 10m Horizontal FOV ≥60°
Overcoming Obstacles ≥10cm Climbing ≥35°
Drop Height ≥4m Working Time ≥2h
CCD Resolution 1/3in，720×576 IR Resolution 384×288@17μm
Driving Capability Foliage, Sandy Slopes, Wading Controller Working Time ≥3.5h
Controller Weight ≤1.2kg（Including Battery） Memory Card 32G（Build In）
Control Method Joystick + Button Remote Control Outdoor ≥350m
Remote Control Indoor ≥50m Operation Temperature －40℃～+55℃
Highlight

Thermal Imaging tracked robot

,

Wheeled tracked robot

,

All terrain tracked robots
Leave a Message
Product Description



Display Brightness Adjustment Supported Wheeled-Tracked Robot With Thermal Imaging



APPLICATIONS

The R30S is a specialized reconnaissance robot, compact and equipped with a wheel-track composite system, capable of entering a scene by being thrown or breaking windows for indoor reconnaissance missions. It can approach targets via remote control, silently lying in wait or actively engaging when necessary. Its crawler design adapts to various challenging terrains, ensuring smooth navigation through underground pipes, caves, jungles, and grasslands. Featuring a "dual vision" setup with a front thermal imaging sensor and a rear visible light sensor, it can capture both thermal and low-light visible images, providing comprehensive reconnaissance day and night. An Auxiliary-Support-Arm allows it to right itself quickly in case of capsizing, ensuring uninterrupted operation.



FUNCTION

►The dual-mode observation with visible light and thermal imaging
►Support IR auxiliary illumination
►Four thermal imaging display modes: white heat,black heat, false color, and outline
►Display of PIP(picture-in-picture)
►Voice monitoring
►Support photo and video recording, local browsing and export
►Can adjust the display brightness
►Support 3-speed change



Features

► Adopt wheel-crawler composite design, showing excellent through performance
► "Double-view"design,free switching between visible light observation mode and thermal imaging observation mode
► Unique arm design,quickly adjust the posture of the body
► Strong impact-resistant design,can be thrown to the target area

► Ultra waterproof performance, excellent wading ability


Technical Parameters:



1. Robot
(1)Weight ≤3kg(Including battery);
(2)Daytime Detection distance 50m, recognition distance 20m;
(3)Night Detection distance 25m, recognition distance 10m;
(4)Horizontal FOV ≥60°;
(5)Overcoming Obstacles ≥10cm;
(6)Climbing ≥35°;
(7)Drop Height ≥4m;
(8)Working Time ≥2h;
(9)CCD Resolution 1/3in,720×576;
(10)IR Resolution 384×288@17μm;
(11)Capable of driving in foliage, sandy slopes and wading;
2.Controller
(1)Working Time ≥3.5h;
(2)Weight ≤1.2kg(Including battery);
(3)Memory Card 32G(Build in);
(4)Control Method: Joystick + button;
3. Remote Control
(1)Outdoor ≥350m;
(2)Indoor ≥50m;
4.IP grade ≥IP67;
5.Operation Temperature －40℃～+55℃.



R30S Details

Display Brightness Adjustment Supported Wheeled Tracked Robot With Thermal Imaging 0
