E Compass Accuracy Anti Sniper Telescope For Tactical Applications

  • E Compass Accuracy Anti Sniper Telescope For Tactical Applications
Place of Origin China
Brand Name Particle
Model Number GLS1000
Minimum Order Quantity 1
Price $12,346
Payment Terms T/T

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Features Highly Integrated, Integrate Multiple Functions All In One; Available Day And Night; Protection Class IP67; It Can Be Used In A Wide Range Of Environments, Such As Deserts, Coastal Areas, Plateaus And Other Harsh Environments; Unique Target Recognition Alg Applications Cutting-Edge Anti-Sniper Solution For Reconnaissance Applications
Safety Distance ≤50m（Does Not Emit Interference Laser For Targets Within 50m） Function Search For Suspicious Targets Of Using Optical Equipment In The Target Area During The Day And Night; Support Laser Ranging; Support Manual/automatic Laser Counteraction; Support Taking Picture And Recording Videos; Support Digital Zoom; Support Image Brig
Laser Ranging Range Accuracy ±2m Detection FOV ≥3︒
Laser Ranging Repeat Frequency 1Hz Laser Ranging Correct Rate ≥98%
Weight ≤3kg Dimension ≤180×110×290mm
Boot Time ≤5s Battery Life ≥4h（normal Temperature）
Operating Temperature -40℃～+55℃ Memory Card 32G
Sensor Resolution 1920×1080 Objective Lens F1.4，80mm
Field Of View（FOV） ≥8︒（H）×6︒（V） Digital Zoom 1×～4×
Diopter -4SD～+5SD Daytime Observation Distance ≥1000m（human）
Night Observation Distance ≥350m（human） Laser Detection Capability（Daytime) ≥1200m（20mmx＜Objective Lens＜50mm）； ≥2500m（Objective Lens≥50mm）
Laser Detection Capability（Night) ≥1800m（20mm＜Objective Lens＜50mm）； ≥4000m（Objective Lens≥50mm） Discovery Probability（Automatic） ≥90%
Laser Wavelength ≥800nm Laser Power Density 0.5mW/cm2～1.25mW/cm2
Laser Range 50m～1500m(For Human) Laser Range Accuracy ±2m
Laser Range Correct Rate ≥98% Repeat Frequency 1Hz
E-Compass Azimuth 0~360° E-Compass Pitch ±90°
E-Compass Angle Measurement Accuracy ≤0.5°（RMS，tilt Range：-15°～15°）
Highlight

E Compass Anti Sniper

,

Accuracy Anti Sniper

,

Tactical anti sniper
Leave a Message
Product Description

E-Compass Accuracy Anti-sniper Telescope for Tactical Applications



Applications



The JP GLS1000 is a versatile handheld detection device, designed with the "cat's eye" effect principle, integrating reconnaissance, detection, and counteraction. It includes a low-light camera and laser detection unit, enabling continuous surveillance. The device scans areas with invisible lasers, capturing suspicious optoelectronic devices instantly. Special algorithms filter out background noise and highlight targets. The built-in laser suppression system allows for manual or automatic high-power laser firing to disable threats. Additionally, its laser ranging unit and digital compass enhance environmental awareness, providing essential data for security personnel to neutralize threats quickly.



Function



  • Search for suspicious targets of using optical equipment in the target area during the day and night;
  • Support laser ranging;
  • Support manual/automatic laser counteraction;
  • Support taking picture and recording videos;
  • Support digital zoom;
  • Support image brightness, contrast and exposure adjustment;
  • Azimuth data display;
  • Low battery warning;
  • Battery reverse polarity protection;
  • Boot self-test;
  • Counteraction-Laser has power-on insurance and work warning functions;
  • Capable to automatically adjust laser spot power density;



Features



  • Highly integrated, integrate multiple functions all in one;
  • Available day and night;
  • Protection class IP67;
  • It can be used in a wide range of environments, such as deserts, coastal areas, plateaus and other harsh environments;
  • Unique target recognition algorithm software to enhance detection probability;
  • Long battery life, meeting the needs of long-term field use;



Technical Parameters



    Main Body

Weight, kg

≤3

Dimension, mm

≤180×110×290

Boot Time, s

≤5

Battery Life,h

≥4(normal temperature)

Operating Temperature, ℃

-40～+55

Memory Card, G

32
    Optical Performance

Sensor Resolution

1920×1080

Objective Lens, mm

F1.4,80

Field of View(FOV)

≥8︒(H)×6︒(V)

Digital Zoom, ×

1～4

Diopter, SD

-4～+5

Daytime Observation Distance, m

≥1000(human)

Night Observation Distance, m

 ≥350(human)
    Laser Detection Capability

Daytime

≥1200m(20mmx＜Objective Lens＜50mm)≥2500m(Objective Lens≥50mm)

Night

≥1800m(20mm＜Objective Lens＜50mm)≥4000m(Objective Lens≥50mm)

Discovery Probability(Automatic)

≥90%

Detection FOV, ︒

≥3

Laser Wavelength, nm

 ≥800
    Laser Counteraction Performance

Laser Power Density

0.5mW/cm2～1.25mW/cm2

Safety Distance

 ≤50m(Does not emit interference laser for targets within 50m)
    Laser Ranging Performance

Range, m

50～1500(For human)

Range Accuracy, m

±2

Correct Rate

≥98%

Repeat Frequency, Hz.

 1
    E-Compass

Azimuth, °

0~360

Pitch, °

±90

Angle Measurement Accuracy, °

 ≤0.5(RMS,tilt range:-15°～15°)





JP GLS1000 Details



E Compass Accuracy Anti Sniper Telescope For Tactical Applications 0
