Handheld Multifunctional Thermal Imaging Telescope For Optimal Performance

  • Handheld Multifunctional Thermal Imaging Telescope For Optimal Performance
  • Handheld Multifunctional Thermal Imaging Telescope For Optimal Performance
Place of Origin China
Brand Name Particle
Model Number NVD3000
Minimum Order Quantity 1
Price $17,000
Payment Terms T/T

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Category Multifunctional Handheld Infrared Night Vision Infrared Detection Resolution 640×512@12um
CMOS Sensor 2592×1944@2.7um Weight ≤1.6kg
Focal Length Adaptation Range 50m～∞ Working Time(Room Temperature ≥10h
Memory Storage 32G Operating Temperature -40℃～+55℃
Infrared Recognition Distance Mid-Size Vehicle：≥2.8km; Standing Man：≥1km Infrared Detector 640×512@12um
Infrared Focal Length 70mm FOV ≥6.3°×5.0°
Visible Light Recognition Distance Mid-Size Vehicle：≥6.6km；Standing Man：≥3km Visible Light Resolution 2592×1944@2.7um
Visible Light Focal Length 105mm Visible Light Focal Length Adaptation Range 50m～∞
Visible Light ≥3.2°×2.4° Laser Ranging （1）Minimum Range：≤50m； （2）Maximum Range：≥6km； （3）Precision：≤2m； （4）Accurate Rate：≥98%； （5）Repeat Frequency：≥0.5Hz
Laser Ranging Logic Select To Display The First Or Last Target Capability Measured Laser Ranging Wavelength Human Eye Safety Band
Positioning Precision ≤7m（CEP），≤10m（PE） Magnetic Azimuth ≤0.5°（RMS）
Target Positioning Accuracy At 2km Of The Distance，≤20m（CEP） Diopter -4SD～+4SD
Digital Zoom 1×~4× Working Time（Room Temperature） ≥10h
IP Grade IP67 External Interface Data USB
External Interface Video PAL Communication RS232
Interface Type Reserved Picatinny Rail Defog Support
Highlight

Handheld thermal imaging telescope

,

Multifunctional thermal imaging telescope

,

IP67 thermal imaging telescopes
Leave a Message
Product Description

50m～∞ Focal Length Adaptation Range Thermal Imaging

Telescope for Optimal Performance



APPLICATIONS



Discover the JP NVD3000, a binocular handheld uncooled thermal imaging telescope designed for multiple functions. It features a thermal imaging detector and a visible light sensor, offering "one-key switch" between thermal and visible light images. The device integrates satellite positioning, laser ranging, and an electronic compass for precise positioning and target data calculation. Perfect for field observation, surveillance, and target location acquisition, the JP NVD3000 meets the diverse needs of users in various environments.

TECHNICAL PARAMETERS

    Product model

NVD3000

    Infrared

Mid-Size Vehicle,km

≥2.8

Standing Man,km

≥1

Infrared detection resolution,Pixel@um

640×512@12um

Lens focal length,mm

70

Infrared FOV,°

≥6.3×5.0

    Visible Light

Mid-Size Vehicle,km

≥6.6

Standing Man,km

≥3

Resolution,Pixel@um

2592×1944@2.7um

Focal Length,mm

105

Focal Length Adaptation Range,m

50～∞

Visible FOV,°

≥3.2×2.4

Defog

Support

    Laser Ranging

Minimum Range,m

≤50

Maximum Range,km

≥6

Precision,m

≤2

Repeat Frequency,Hz

≥0.5

Ranging Logic

Select to display the first or last target capability measured

Laser Wavelength

Human eye safety band

    Positioning Orientation

Positioning Precision,m

≤7(CEP), ≤10(PE)

Magnetic Azimuth,°

≤0.5(RMS)

Target Positioning Accuracy,m

at 2km of the distance, ≤20(CEP)

    Other

Diopter,SD

-4～+4

Digital zoom,×

1~4

Working Time(Room temperature),h

≥10

Memory Storage,G

32

Operating Temperature,℃

-40～+55

IP Grade

IP67

Weight,kg

≤1.6



* These parameters are for illustrative purposes only and are subject to change without prior notice due to product updates and improvements.



PRODUCT DETAILS



Handheld Multifunctional Thermal Imaging Telescope For Optimal Performance 0



► Thermal imaging observation mode and visible light observation mode can be switched with one click, and screen brightness, contrast, image quality enhancement, etc. can be personalized


Handheld Multifunctional Thermal Imaging Telescope For Optimal Performance 1


► Supports guided search function after entering target coordinates



Handheld Multifunctional Thermal Imaging Telescope For Optimal Performance 2



► PIP



Handheld Multifunctional Thermal Imaging Telescope For Optimal Performance 3


► Supports fog penetration function in visible light (color, black and white) observation mode



Handheld Multifunctional Thermal Imaging Telescope For Optimal Performance 4


► Laser ranging and real-time display of distance, longitude, latitude, elevation and other data of the measured target



Handheld Multifunctional Thermal Imaging Telescope For Optimal Performance 5


► Relative ranging function supports relative distance calculation between targets



Handheld Multifunctional Thermal Imaging Telescope For Optimal Performance 6
